SYLVAC Digital Måletaster P12D 0-12,7 mmx0,01 um med M8 tilslutning (High Resolution-801.1212)
Tilføj til kurv
Forespørg pris
Produktbeskrivelse
- High-precision measuring probes with patented measuring system combining inductive and capacitive technologies
- Absolute system with integrated electronic error correction (no more pairing with the unit or computer) guaranteeing high accuracy over the entire measuring range
- Extremely robust ball bearing guide guarantees a minimum of 100 million cycles (30 millions with radial load)
- Stainless steel body Ø 12 mm, fixing diameter 8 h6
- Measuring range 12.7 mm
- Available in 3 versions: Standard, Work and Pro
- Measuring force selectable: low or very low for vertical use only
- Output signal in direct digital format without the need for a converter
- Reading speed up to 100 values per second depending on configuration
- Straight cable length 2m with either USB or M8 connector
- Cable outlet protected by a spring which can be tilted by 90° with the optional accessory 801-5101
- Protection class IP54
Produktspecifikationer
-
Barcode7640125715552
-
Aflæsning0,01 µm
-
Data udgangM8
-
Fejlgrænse0,6 µm
-
Gentagelsesnøjagtighed0,08 µm
-
IP KlasseIP54
-
Måleområde0-12,7 mm
-
ModelP12D HR M8
-
Nøjagtighed0,6 µm
-
SYLVAC varenr.801-1212
-
VaremærkeSYLVAC
-
Brutto vægt0,200 kg
-
Netto vægt0,200 kg
